All-Terrain Electric Pallet Jack
Models: PT - 03
3,000 kg
Load Capacity
30%
Max. Gradeability
Off-Road 300-100 Polyurethane
Tires
48V / 32Ah — Full Shift Operation
Battery
The HJ All-Terrain Electric Pallet Jack is engineered for challenging surfaces, featuring heavy-duty off-road tires and a fully electric drive system. Capable of climbing slopes up to 30%, it is purpose-built for outdoor yards, construction sites, and uneven floor applications where standard jacks cannot operate.
Get a quote
Features
Gallery
Specifications
| Specification | Unit | Value |
| Rated Load | kg | 3,000 |
| Operation Type | — | Fully Electric |
| Body Weight | kg | 205 |
| Motor Power | W | 1,500 |
| Controller Current | A | 45 |
| Battery | V/Ah | 48V / 32Ah Lead Acid |
| Load Wheel | — | 300-100 Polyurethane |
| Rear Wheel | — | 80-70 Polyurethane |
| Fork Height from Ground | mm | 80 – 200 |
| Fork Distance | mm | 550 / 685 |
| Fork Width | mm | 160 |
| Effective Fork Length | mm | 1,200 |
| Full Length incl. Handle | mm | 1,700 |
| Min. Turning Radius | m | 1.6 |
| Gradeability full / unloaded | % | 15 / 30 |
| Vehicle Size (L×W×H) | cm | 170 × 68.5 × 120 |
| Vehicle Weight | kg | 150 – 195 |
